Lexmark MS821

Assembly 16: 250- and 550-sheet tray options 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
141X1655 1 1Interface cable
“250‑ and 550-sheet tray interface
cable removal” on page 510
241X1093 1 1Sensor (pick)
“Sensor (250‑ and 550-sheet tray pick)
removal” on page 507
341X1094 1 1Sensor (pass‑through)
“Sensor (250‑ and 550-sheet tray
pass‑through) removal” on page 507
4 41X1653 1 1 Right cover (optional
250-sheet tray)
“250‑ and 550-sheet tray right cover
removal” on page 498
4 41X1661 1 1 Right cover (optional
550-sheet tray)
“250‑ and 550-sheet tray right cover
removal” on page 498
5 41X1120 1 1 Paper size sensor
actuator
“250‑ and 550-sheet tray paper size
sensor actuator removal” on page 513
6 41X1108 1 1 Pick roller
“Pick roller removal” on page 503
7 41X1651 1 1 Front cover (250-sheet
tray insert)
“250‑ and 550-sheet tray insert front
cover removal” on page 502
7 41X2304 1 1 Front cover (550-sheet
tray insert)
“250‑ and 550-sheet tray insert front
cover removal” on page 502
8 40X7911 1 1 Sensor (paper size)
“Sensor (250‑ and 550-sheet tray paper
size) removal” on page 512
9 41X1656 1 1 Motor (transport)
“Motor (250‑ and 550-sheet tray
transport) removal” on page 504
10 41X1657 1 1 Controller board
(optional 250-sheet
tray)
“250‑ and 550-sheet tray controller
board removal” on page 506
10 41X2194 1 1 Controller board
(optional 550-sheet
tray)
“250‑ and 550-sheet tray controller
board removal” on page 506
11 41X1652 1 1 Left cover (optional
250-sheet tray)
“250‑ and 550-sheet tray left cover
removal” on page 496
11 41X1660 1 1 Left cover (optional
550-sheet tray)
“250‑ and 550-sheet tray left cover
removal” on page 496
12 41X1107 1 1 Paper feeder
“250‑ and 550-sheet tray paper feeder
removal” on page 504
13 41X1083 1 1 Sensor (paper present)
“Sensor (250‑ and 550-sheet tray paper
present) removal” on page 509
14 41X1083 1 1 Sensor (pick roller
index)
“Sensor (250‑ and 550-sheet tray pick
roller index) removal” on page 508
15 41X1654 1 1 Rear cover (optional
250-sheet tray)
“250‑ and 550-sheet tray rear cover
removal” on page 501
4064
Parts catalog
802
