Lexmark MS821

Assembly 19: 2100‑sheet tray option 3
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X1083 1 1 Sensor (2100-sheet tray
near empty)
“Sensor (2100-sheet tray near
empty) removal” on page 490
2 41X1083 1 1 Sensor (2100‑sheet tray
A5 length guide)
“Sensor (2100-sheet tray A5 length
guide) removal” on page 491
3 40X8177 1 1 2100-sheet tray elevator
sensor actuator
‑‑
4 40X7911 1 1 Sensor (2100-sheet tray
paper size)
“Sensor (2100-sheet tray paper size)
removal” on page 485
5 40X4585 2 1 2100-sheet tray bellcrank
“2100-sheet tray bellcrank removal”
on page 488
6 41X1108 1 1 2100-sheet tray pick roller ‑‑
7 41X1094 1 1 Sensor (2100-sheet tray
pick)
“Sensor (2100-sheet tray pick)
removal” on page 483
8 41X1683 1 1 2100-sheet tray paper
feeder
“2100-sheet tray paper feeder
removal” on page 493
9 41X1083 1 1 Sensor (2100-sheet tray
pick roller index)
“Sensor (2100-sheet tray pick roller
index) removal” on page 491
10 41X1083 1 1 Sensor (2100-sheet tray
paper present)
“Sensor (2100-sheet tray paper
present) removal” on page 492
