Lexmark MS821

Assembly 22: Output expander 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8187 1 1 Output expander right
cover
“Output expander right cover removal”
on page 520
240X8721 2 1Output expander latch
“Output expander latch removal” on
page 528
341X2193 1 1Output expander
spring with string
“Output expander spring with string
removal” on page 527
4 40X8732 1 1 Output expander drive
belt
“Output expander drive belt removal”
on page 540
540X8718 1 1Output expander belt
tensioner
“Output expander belt tensioner
removal” on page 540
4064
Parts catalog
816
