Lexmark MS821

Assembly 25: High capacity output expander 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
140X8202 1 1HCOE left cover
“HCOE left cover removal” on page
550
240X8730 1 1Motor (HCOE
transport)
“Motor (HCOE transport) removal” on
page 568
3 40X8206 1 1 HCOE upper interface
cable
“HCOE upper interface cable removal”
on page 554
4 40X8199 1 1 HCOE controller board
“HCOE controller board removal” on
page 552
5 40X8205 1 1 HCOE lower interface
cable
“HCOE lower interface cable removal”
on page 553
640X8721 2 1HCOE latch
“HCOE latch removal” on page 554
740X8256 1 1Motor (HCOE diverter)
“Motor (HCOE diverter) removal” on
page 556
8 40X8731 2 1 HCOE bin pinion
“HCOE bin pinion removal” on
page 558
9 40X8733 2 1 HCOE bin spring
“HCOE bin spring removal” on
page 557
10 40X7592 1 1 Sensor (HCOE rear
door interlock)
“Sensor (HCOE rear door interlock)
removal” on page 559
11 40X8728 1 1 Sensor (HCOE bin)
“Sensor (HCOE bin) removal” on
page 556
12 40X8726 1 1 HCOE drive gear
assembly
“HCOE drive gear assembly removal”
on page 566
13 40X8722 1 1 HCOE diverter plunger
assembly
“HCOE diverter plunger assembly
removal” on page 564
14 40X7592 1 1 Sensor (HCOE
diverter)
“Sensor (HCOE diverter) removal” on
page 570
