Lexmark MS821

Assembly 27: High capacity output expander 3
Asm-index P/N Units/mach Units/FRU Description Removal procedure
140X8198 1 1HCOE right cover
“HCOE right cover removal” on
page 549
2 40X8192 1 1 HCOE spring with string ‑‑
3 40X8733 2 1 HCOE bin spring
“HCOE bin spring removal” on
page 557
440X8721 2 1HCOE latch
“HCOE latch removal” on page 554
5 40X8732 1 1 HCOE drive belt
“HCOE drive belt removal” on
page 561
6 40X8731 2 1 HCOE bin pinion
“HCOE bin pinion removal” on
page 558
7 40X8718 1 1 HCOE belt tensioner
“HCOE belt tensioner removal” on
page 563
