Lexmark MS821

Assembly 28: High capacity output expander 4
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8196 1 1 HCOE top cover
“HCOE top cover removal” on
page 545
2 40X8715 1 1 HCOE sensor cover
“HCOE sensor cover removal” on
page 547
3 40X8712 1 1 HCOE bin full flag
“HCOE bin full flag removal” on
page 548
4 40X8191 1 1 Sensor (HCOE bin full)
with flag
“Sensor (HCOE bin full) with flag
removal” on page 548
4064
Parts catalog
828
