Lexmark MS821

Assembly 30: Staple finisher 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X2175 1 1 Staple finisher drive
gear assembly
“Staple finisher drive gear assembly
removal” on page 604
2 41X0529 1 1 Motor (staple finisher
transport)
“Motor (staple finisher transport)
removal” on page 599
3 41X0802 1 1 Sensor (staple finisher
bin full)
“Sensor (staple finisher bin full send)
removal” on page 608 and “Sensor
(staple finisher bin full receive)
removal” on page 609
4 40X8213 1 1 Motor (staple finisher
paddle)
“Motor (staple finisher paddle)
removal” on page 592
541X2187 1 1Staple finisher stack
height assembly
“Staple finisher stack height assembly
removal” on page 629
6 41X0798 1 1 Sensor (staple finisher
stack height)
‑‑
7 41X1238 1 1 Sensor (staple finisher
rear door interlock)
“Sensor (staple finisher rear door
interlock) removal” on page 612
8 41X1238 1 1 Sensor (staple finisher
paddle)
“Sensor (staple finisher paddle)
removal” on page 618
941X2192 1 1Paddle spring ‑‑
10 40X8742 2 1 Staple finisher bin
spring
“Staple finisher bin spring removal” on
page 613
11 40X8744 2 1 Staple finisher bin link
assembly
“Staple finisher bin link assembly
removal” on page 614
12 40X8721 2 1 Staple finisher latch
“Staple finisher latch removal” on
page 616
13 40X8224 1 1 Staple finisher interface
cable
“Staple finisher interface cable
removal” on page 595
14 41X0798 1 1 Sensor (staple finisher
diverter plunger)
“Sensor (staple finisher diverter
plunger) removal” on page 599
15 40X8256 1 1 Motor (staple finisher
diverter)
“Motor (staple finisher diverter)
removal” on page 598
16 41X2279 1 1 Staple finisher
controller board
“Staple finisher controller board
removal” on page 590
17 40X8722 1 1 Staple finisher diverter
plunger assembly
“Staple finisher diverter plunger
assembly removal” on page 604
4064
Parts catalog
832
