Assembly 31: Staple finisher 3
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8745 1 1 Sensor (staple throat
paper present)
“Sensor (staple throat paper present)
removal” on page 644
2 40X8742 2 1 Staple finisher bin
spring
“Staple finisher bin spring removal” on
page 613
3 40X8744 2 1 Staple finisher bin link
assembly
“Staple finisher bin link assembly
removal” on page 614
4 40X8721 2 1 Staple finisher latch
“Staple finisher latch removal” on
page 616
5 41X0802 1 1 Sensor (staple finisher
bin full send)
“Sensor (staple finisher bin full send)
removal” on page 608
6 40X8226 1 1 Staple finisher spring
with string
“Staple finisher spring with string
removal” on page 617
7 41X0654 1 1 Staple unit
“Staple unit removal” on page 592
8 41X2198 1 1 Staple cartridge door
close limit switch
“Staple cartridge door close limit
switch removal” on page 647
4064
Parts catalog
834
