Lexmark MS821

Assembly 32: Staple finisher 4
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8212 2 1 Tamper drive belt
“Tamper drive belt removal” on
page 620
2 41X1705 2 1 Tamper spring
“Tamper drive belt removal” on
page 620
3 40X8211 1 1 Motor (staple finisher
right tamper)
“Motor (staple finisher right tamper)
removal” on page 619
4 40X8211 1 1 Motor (staple finisher
left tamper)
“Motor (staple finisher left tamper)
removal” on page 619
5 41X1704 1 1 Staple finisher bin LED
“Staple finisher bin LED removal” on
page 625
6 41X0664 2 1 Tamper gear
“Tamper drive belt removal” on
page 620
741X2196 2 1Tamper bracket ‑‑
8 41X1238 1 1 Sensor (staple finisher
left tamper)
“Sensor (staple finisher left tamper)
removal” on page 623
9 41X2160 1 1 Tamper aligner
“Tamper aligner removal” on page
627
10 41X1238 1 1 Sensor (staple finisher
right tamper)
“Sensor (staple finisher right tamper)
removal” on page 621
4064
Parts catalog
836
