Lexmark MS821

Assembly 34: Mailbox 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8246 1 1 Mailbox left cover
“Mailbox left cover removal” on
page 654
2 40X8254 1 1 Mailbox upper interface
cable
“Mailbox upper interface cable
removal” on page 672
3 40X8253 1 1 Mailbox lower interface
cable
“Mailbox lower interface cable
removal” on page 670
4 40X8244 1 1 Mailbox controller
board
“Mailbox controller board removal” on
page 667
5 40X8256 1 1 Motor (mailbox diverter)
“Motor (mailbox diverter) removal” on
page 672
6 41X0529 1 1 Motor (mailbox
transport)
“Motor (mailbox transport) removal”
on page 666
7 40X7592 1 1 Sensor (mailbox rear
door interlock)
“Sensor (mailbox rear door interlock)
removal” on page 658
840X7592 1 1Sensor (mailbox
diverter plunger)
“Sensor (mailbox diverter plunger)
removal” on page 668
9 40X8721 2 1 Mailbox latch
“Mailbox latch removal” on page 657
10 40X8726 1 1 Mailbox transport drive
gear
“Mailbox transport drive gear removal”
on page 663
11 40X8722 1 1 Mailbox diverter
plunger assembly
“Mailbox diverter plunger assembly
removal” on page 658
12 41X0701 4 1 Sensor (mailbox bin full)
“Sensor (mailbox bin full) removal” on
page 675
13 40X8247 4 1 Mailbox bin full flag
“Mailbox bin full flag removal” on
page 674
NS 40X8500 1 1 Optional bin guide bar ‑‑
4064
Parts catalog
840
