Lexmark MS821

Assembly 35: Mailbox 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8250 1 1 Mailbox bin LED
assembly
“Mailbox bin LED assembly removal” on
page 680
2 40X8249 4 1 Mailbox belt
“Mailbox belt removal” on page 678
3 40X8252 1 1 Mailbox spring with
string
“Mailbox spring with string removal” on
page 653
4 40X8721 2 1 Mailbox latch
“Mailbox latch removal” on page 657
5 40X8251 3 1 Mailbox solenoid
“Mailbox solenoid removal” on
page 655
6 40X8243 1 1 Mailbox right cover
“Mailbox right cover removal” on
page 651
4064
Parts catalog
842
