Assembly 37: Staple, hole punch finisher 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8547 1 1 Staple, hole punch
finisher top cover
“Staple, hole punch finisher top
cover removal” on page 703
2 41X1719 1 1 Staple, hole punch
finisher right cover
“Staple, hole punch finisher right
cover removal” on page 701
3 41X1701 1 1 Staple cartridge access
door
“Staple cartridge access door
removal” on page 644
4 41X2202 1 1 Hole punch box ‑‑
5 40X7466 1 1 Staple cartridge holder
“Staple cartridge holder removal” on
page 704
641X1704 1 1Standard bin LED ‑‑
7 41X0724 1 1 Sensor (SHPF bin paper
present)
‑‑
8 41X1718 1 1 Staple, hole punch
finisher left cover
“Staple, hole punch finisher left
cover removal” on page 699
941X2166 1 1Left staple cartridge
access door
“Left staple cartridge access door
removal” on page 699
4064
Parts catalog
846
