Assembly 38: Staple, hole punch finisher 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8212 2 1 Tamper drive belt ‑‑
241X1705 2 1Tamper spring ‑‑
3 40X8211 1 1 Motor (SHPF right tamper) ‑‑
4 40X8211 1 1 Motor (SHPF left tamper) ‑‑
5 41X1704 1 1 Staple, hole punch finisher bin LED ‑‑
641X0664 2 1Tamper gear ‑‑
7 41X2196 2 1 Tamper bracket ‑‑
8 41X1238 1 1 Sensor (SHPF left tamper) ‑‑
941X2160 1 1Tamper aligner ‑‑
10 41X1238 1 1 Sensor (SHPF right tamper) ‑‑
