Assembly 39: Staple, hole punch finisher 3
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X2175 1 1 SHPF drive gear
assembly
“SHPF drive gear assembly removal”
on page 716
2 41X0529 1 1 Motor (SHPF transport)
“Motor (SHPF transport) removal” on
page 713
341X0802 1 1Sensor (SHPF bin full)
“Sensor (SHPF bin full send) removal”
on page 734 and “Sensor (SHPF bin
full receive) removal” on page 735
4 40X8213 1 1 Motor (SHPF paddle)
“Motor (SHPF paddle) removal” on
page 706
5 41X2187 1 1 SHPF stack height
assembly
‑‑
641X0798 1 1Sensor (SHPF stack
height)
‑‑
7 41X1238 1 1 Sensor (SHPF rear door
interlock)
“Sensor (SHPF rear door interlock)
removal” on page 718
8 41X1238 1 1 Sensor (SHPF paddle)
“Sensor (SHPF paddle) removal” on
page 737
941X2192 1 1Paddle spring ‑‑
10 41X1710 2 1 SHPF bin link tension
spring
“SHPF bin link tension spring
removal” on page 732
11 40X8744 2 1 SHPF bin link assembly
“SHPF bin link assembly removal” on
page 733
12 40X8721 2 1 Staple, hole punch
finisher latch
“Staple, hole punch finisher latch
removal” on page 737
13 40X8224 1 1 Staple, hole punch
finisher interface cable
“Staple, hole punch finisher interface
cable removal” on page 711
14 41X0798 1 1 Sensor (SHPF diverter
plunger)
‑‑
15 40x8256 1 1 Motor (SHPF diverter
plunger)
“Motor (SHPF diverter plunger)
removal” on page 712
16 41X1708 1 1 Staple, hole punch
finisher controller board
“Staple, hole punch finisher controller
board removal” on page 705
17 40X8722 1 1 SHPF diverter plunger
assembly
“SHPF diverter plunger assembly
removal” on page 715
4064
Parts catalog
850
