Lexmark MS821

Assembly 40: Staple, hole punch finisher 4
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X0654 1 1 Left staple unit
“Left staple unit removal” on page
709
2 40X8745 2 1 Sensor (SHPF staple
throat paper present)
“Left staple unit removal” on page
709
3 41X2175 1 1 SHPF drive gear
assembly
“Punch drive gears removal” on
page 720
4 41X1709 1 1 Staple, hole punch
finisher elevator drive
“Staple, hole punch finisher elevator
drive removal” on page 722
5 41X0709 1 1 Sensor (SHPF elevator,
top)
“Staple, hole punch finisher elevator
drive removal” on page 722
6 41X0709 1 1 Sensor (SHPF elevator,
bottom)
“Staple, hole punch finisher elevator
drive removal” on page 722
