Lexmark MS821

Assembly 41: Staple, hole punch finisher 5
Asm-index P/N Units/mach Units/FRUDescription Removal procedure
1 41X1702 1 1 SHPF staple cartridge
door close limit switch
“SHPF staple cartridge door close limit
switch removal” on page 706
2 41X0654 1 1 Right staple unit
“Right staple unit removal” on page
726
3 40X8745 2 1 Sensor (SHPF staple
throat paper present)
“Sensor (SHPF staple throat paper
present) removal” on page 729
4 40X8742 2 1 SHPF bin link tension
spring
“SHPF bin link tension spring removal”
on page 732
540X8744 2 1SHPF bin link
assembly
“SHPF bin link assembly removal” on
page 733
6 41X0802 1 1 Sensor (bin full)
“Sensor (SHPF bin full send) removal”
on page 734 and “Sensor (SHPF bin full
receive) removal” on page 735
7 41X1238 1 1 Sensor (hole punch
box present)
“Sensor (hole punch box present)
removal” on page 728
8 41X2178 1 1 Motor (HPU carriage)
“Motor (HPU carriage) removal” on
page 726
940X8721 2 1Staple, hole punch
finisher latch
“Staple, hole punch finisher latch
removal” on page 737
4064
Parts catalog
854
