Lexmark MS821

Clean
1 Photoconductor drum
2 Cleaning blade
3 Augers
4 Cleaning roller
5 Charge roller
6 Waste toner chamber
The cleaning blade removes the toner residue from the photoconductor drum. The cleaning roller removes the
toner residue from the charge roller. The cycle (charge, expose, develop, transfer, clean) repeats until the whole
image is transferred to the paper.
4064
Theory of operation
865
