L-INX User Manual 109 LOYTEC
Version 4.0 LOYTEC electronics GmbH
Setting this property to true can be beneficial when used in a connection to withdraw a
value in another technology.
Server Object Name: This property defines the object name of the underlying BACnet
server object. It must be unique among all server objects. It can be up to 64 characters.
Server Object Instance No: This property defines the object instance number of the
underlying BACnet server object.
Server Object Description: This property defines the object description of the
underlying BACnet server object. It can be left blank.
Server Object Device Type: This property defines the object device type of the
underlying BACnet server object. It can be left blank.
Allocate Server Object: This Boolean property defines, if a server object shall be
allocated for the data point. This option is useful, when a local server object shall be
allocated for a client mapping.
Allocate Client Mapping: This Boolean property defines, if a client mapping shall be
allocated for the data point. This option is always set, if at least on client mapping is
attached.
Client Map Count: This property defines the number of client mappings attached to a
data point. A data point can have one read client map or n write client mappings.
Client Map [n]: This is a list of client mappings. The property shows a summary of the
client mapping parameters. To edit a client mapping click on the … button.
Confirmed COV: This Boolean property defines, if a client map subscribes with the
confirmed COV service. If not enabled, the unconfirmed COV is used.
6.3 Project Settings
The project settings allow defining certain default behavior and default settings used
throughout the project. To access the project settings go to the menu Settings Project
Settings…. This opens the project settings dialog, which provides several tabs as described
in the following sections.
6.3.1 General
The general tab of the project settings as shown in Figure 84 contains settings independent
of the technology port. The settings are:
Project Name: This setting allows entering a descriptive name for the project.
Device Configuration Download Default: This group of settings defines, how the
download of device configuration parameters shall proceed. If Download only data
point configuration is selected, the configuration download does not download
anything else than the data point configuration. If Ask is selected, the download will
pop up a dialog in which the user can choose what to download. If Download specific
is selected, the project settings of this dialog determine what is downloaded onto the
device. As a default, the configuration download includes the schedules and calendar
patterns but does not include the device settings as defined in the Device
Configuration tab (see Section 6.3.6).
Automatically add downloaded device to the OPC Bridge: This option is only
available, if LOPC-BR800, the LOYTEC OPC bridge software, is installed on the same
PC. If enabled, the LINX-20X device, a configuration is downloaded to, is
automatically added to the OPC server list in the bridge. For more information on using
LOPC-BR800 refer to Section 9.3.
