3. If more than one calendar pattern is used, edit the priorities. For example, if a given
calendar day falls in both categories, ―Holidays‖ and ―Maintenance‖, the exception day
with the higher priority becomes effective on that day. The highest available priority is
marked highest. Note that the actual priority values depend on the technology (see
Section 5.5.3).
Important! Choose different priorities for different exceptions. If two exceptions are valid for a given
day and their priorities are equal, it is not determined, which exception is in effect.
6.12.6 Configure Exception Days
When a local calendar is used, its calendar patterns need to be configured with exception
days (pattern entries). The calendar patterns can be configured in the LINX-100/200
Configurator software or be modified at run-time over the Web UI or over the network.
When configuring in the software, the current exception days should be uploaded from the
device, to work on the current configuration.
To Configure Exception Days in a Calendar Pattern
1. Click on the Upload calendar/scheduler configuration button
in the tool bar of the main connections window. Click OK when the upload is finished.
2. Select the Calendar sub-folder and select the calendar pattern, which shall be
configured
3. Right-click and select Configure Pattern … in the context menu.
4. The Configure Pattern dialog appears as shown in Figure 142. Add dates to the
calendar pattern by entering a Date Configuration. Then click Add Entry. The date
appears in the Pattern Entries list on the right-hand side.
5. Edit an exception by selecting the pattern entry in the Pattern Entries list. Then
modify the date configuration in the Date Configuration group box.
