L-INX User Manual 37 LOYTEC

Version 4.0 LOYTEC electronics GmbH

3 Hardware Installation

3.1 Enclosure

3.1.1 LINX-10X/11X

The LINX-10X/11X enclosure is 107 mm wide for DIN rail mounting, following

DIN 43 880 (see Figure 22).

1 2 3

Status Button

and LED

1 2 3 4 5 6 7

DIP Switch

Console

Connector

Power

LED

FT, CNIP

Status LEDs

Ethernet

OPC/PLC

Status

LED

4 5 6

15 16 17

Ethernet

LEDs

CS/RNI

LED

Figure 22: LINX-10X/11X Enclosure (dimensions in mm).
