Behavior
Description
Comment
GREEN flashing fast
Traffic
GREEN flashing at 1Hz
The OPC node or LINX-101‘s router port is
unconfigured
On the LINX-101 this LED only
stops flashing if both, node and
router, are commissioned.
RED permanent
Port damaged
RED flashing fast
Traffic with high amount of errors
RED flashing at 1 Hz
(all ports)
Firmware image corrupt
Please upload new firmware.
ORANGE permanent
Port disabled
e.g., using LSD Tool
ORANGE flashing fast
Traffic on port configured as management port
e.g., using LSD Tool
Table 3: CEA-709 Activity LED Patterns.
3.4.6 MSTP Activity LED
The MS/TP port has a three-color MSTP Activity LED (see Figure 24). Table 4 shows the
different LED patterns of the port and their meaning. A permanent color reflects a state.
Flicker is for 25 ms when there is activity on the MS/TP data link layer.
Behavior
Description
Comment
GREEN permanently,
flicker off
Multi-Master, token ok, flicker when traffic
Normal condition on a multi-master
MS/TP network.
ORANGE flicker
Sole master, flicker when traffic
Normal condition on a single-master
MS/TP network.
RED permanent, flicker
GREEN
Token lost state, flicker when transmit
attempt
Cable might be broken.
RED flash fast
Transmission or receive errors
This indicates bad cabling.
Table 4: MS/TP Activity LED Patterns.
3.4.7 Ethernet Link LED
The Ethernet Link LED lights up green whenever an Ethernet cable is plugged-in and a
physical connection with a switch, hub, or PC can be established.
3.4.8 Ethernet Activity LED
The Ethernet Activity LED lights up green for 6 ms whenever a packet is transmitted or
received or when a collision is detected on the network cable.
3.4.9 CNIP LED
This LED is available on L-INX models 10X, 11X only. The CNIP LED is a three color
LED that indicates different operating states of the device‘s CEA-852 device.
Green: The CEA-852 device is fully functional and all CEA-852 configuration data
(channel routing info, channel membership list, send list) are up-to-date.
Green flicker: If a valid CEA-709 packet is received or transmitted over the IP channel the
CNIP LED turns off for 50 ms. Only valid CEA-709 IP packets sent to the IP address of the
LINX-10X can be seen. Stale packets or packets not addressed to the device are not seen.
Yellow: Device is functional but some configuration data is not up-to-date (device cannot
contact configuration server but has configuration data saved in Flash memory)
