LOYTEC L-INX - Node Object

L-INX User Manual 280 LOYTEC
Version 4.0 LOYTEC electronics GmbH
Column
Field
Example
Description
A
SNVT
39
A numeric value of the SNVT (as defined in the SNVT
master list). The example value 39 represents a
SNVT_temp.
B
NV index
0
The NV index in decimal notation of the NV on the
network node. Index starts at 0.
C
NV selector
1
The NV selector in decimal notation of the NV on the
network node.
D
NV name
nvoTemp
The NV programmatic name of the NV on the network
node.
E
is output
1
Defines if this NV is an output on the network node. ‗1‘
means the NV is an output on the network node.
F
flag auth cfg
1
‗1‘ defines that authentication can be configured for this
NV on the network node.
G
flag auth
0
‗1‘ defines that the NV is authenticated.
H
flag priority cfg
1
‗1‘ defines that the priority can be configured for this
NV on the network node.
I
flag priority
0
‗1‘ defines that the NV is using priority.
J
flag service type
cfg
1
‗1‘ defines that the service type can be configured for
this NV on the network node.
K
flag service ack
1
‗1‘ defines that the NV is using acknowledged service.
L
flag polled
0
‗1‘ defines that the NV is using the polled attribute
M
flag sync
0
‗1‘ defines that the NV is a synchronous NV.
N
Deviceref
1
This field is a numeric reference to a device description.
If it is the first occurrence of this reference in the file,
the columns defined below must be filled in. Otherwise,
they can be left out.
O
programID
9000A44850060402
The program ID string of the network device.
P
neuronID
80000000C8C8
The NID of the network device.
Q
Subnet
2
The subnet address of the network device. Use ‗0‘ if the
device has no subnet address information.
R
Node
3
The node address of the network device. Use ‗0‘ if the
device has no node address information.
S
location str
0
The location string of the network device. Use ‗0‘ if no
information is available.
T
Device name
DDC
The device name of the network device. Leave this field
blank if this information is not available.
U
node self-doc
&3.2@0,2
Self-documentation string of the device (special
characters are escaped)
V
NV length
2
NV length in bytes
W
NV self-doc
@0|4
NV self-documentation string (special characters are
escaped)
X
Allocation
1
Define, how this NV shall be allocated: external=1
(default) / static=2 / file=3
Table 14: CSV Columns of the NV Import File.
13.2.2 Node Object
The L-INX provides a node object conforming to the LONMARK guidelines.
 The Node Object accepts the following commands via nviRequest: RQ_NORMAL,
RQ_UPDATE_STATUS, RQ_REPORT_MASK, RQ_ENABLE, RQ_DISABLE,
RQ_UPDATE_ALARM, RQ_CLEAR_ALARM, RQ_RESET, RQ_CLEAR_RESET
