Timestamp: transmission time.
Frame Type: RTU, ASCII or Damaged when something happened with the frame.
Dir.: direction. Either SND (send) or RCV (receive)
Addr.: Slave address
CRC: CRC of the transmission
Length: Payload length of the data frame
Payload: Payload in hexadecimal numbers (this column cannot be used for
sorting)
Figure 199: Typical protocol analyzer output for Modbus RS-485 port.
