Manitowoc GROVE GMK3060

Malfunctions in driving mode
8.7 Fuses on the carrier
8 - 46 3 302 819 en Operating manual
GMK3060
13.12.2018
Designation Amperage (A) Function
F4/1 3 Cab lighting
F4/2 20 Dual tank switchover
F4/3 5 CCS display
F4/4 15 Fuel filter heating system
F4/5 15 Air intake inhibitor
F4/6 - Unassigned
F4/7 - Unassigned
F4/8 - Unassigned
Designation Amperage (A) Function
F5/1 10 Radio
F5/2 15
AdBlue (DEF) heater
Auxiliary heater
F5/3 20 Auxiliary heater
F5/4 15 Battery heater
F5/5 10 Fan
F5/6 5 Control unit auxiliary heater
F5/7 5 Tachograph
F5/8 5 Power supply relay
