Malfunctions in driving mode
8.7 Fuses on the carrier
Operating manual 3 302 819 en 8 - 47
GMK3060
13.12.2018
s
Designation Amperage (A) Function
F6/1 5
Engine emergency stop switch
Tachograph, instrument panel
F6/2 3
Control unit CCM 11
Control unit IOL 31/32/33
F6/3 3
CCS display
Reversing camera
Radio
F6/4 - Unassigned
F6/5 10 Gearbox control
F6/6 5 Engine/transmission diagnostics plug
F6/7 3
Outrigger control panel left/right
Inclination transmitter
F6/8 3
Engine electronic control system
AdBlue (DEF) system
Flame start system
Designation Amperage (A) Function
F7/1 3 Alternator
F7/2 10 auxiliary heater
F7/3 10 Dual tank
F7/4 15 Retarder
F7/5 5 Horn
F7/6 10 Power supply to the AdBlue (DEF) system
F7/7 10
Operating the mirror adjustment
Window winder
F7/8 3 Brake circuits 1 and 2
