Malfunctions in driving mode
8.7 Fuses on the carrier
8 - 48 3 302 819 en Operating manual
GMK3060
13.12.2018
Designation Amperage (A) Function
F8/1 5 Central lubrication
F8/2 15 Windscreen wiper
F8/3 10 Trailer socket
F8/4 3
ABS
ABS trailer
F8/5 10 Air-conditioning system coupling
F8/6 15 Blower heating system
F8/7 5 Steering coupling
F8/8 5 Air drier
Designation Amperage (A) Function
F9/1 2
Temperature gauge
Fuel gauge
F9/2 2 Cruise control
F9/3 Unassigned
F9/4 - Unassigned
F9/5 - Unassigned
F9/6 - Unassigned
F9/7 - Unassigned
F9/8 - Unassigned
