Driving with a rigged truck crane
13.5 Driving from the crane cab
Operating manual 3 302 819 en 13 - 21
GMK3060
13.12.2018
Steering with separate steering – automatic
The symbol (2) or (3) is displayed for the desired steering mode.
• Steer the 1st axle line with the button (1).
The axle lines are steered as long as you keep the button pressed or until an end
position is reached.
The electronics measures the steering angle of the 1st axle line and automatically
steers the wheels of the 2nd and 3rd axle lines correspondingly.
(A) – When driving around corners
The 2nd and 3rd axle lines are steered out in line
with the turning radius, against the steering angle
on the 1st axle line.
(B) – For crab travel mode
The 2nd and 3rd axle lines are steered in the
same direction as the 1st axle line.
s
– To turn to the left: • Press button (1) to the left.
– To turn to the right:
• Press button (1) to the right.
