Malfunctions during crane operation
14.8 Fuses in the crane cab
14 - 74 3 302 819 en Operating manual
GMK3060
13.12.2018
Designation Amperage (A) Function
F4/1 10
Cigarette lighter
diagnostics plug
F4/2 5 Camera
F4/3 5 rotating beacon
F4/4 3
Remote control
CraneStar system
F4/5 10 Houselock
F4/6 3 Spotlight
F4/7 10
Radio
Voltage transformer 24/12 V
F4/8 7.5 Power supply to the comfort seat
Designation Amperage (A) Function
F5/1 20 auxiliary air heater
F5/2 5
Control unit for auxiliary air heating system
CraneStar system
F5/3 3 Control units UE IOS 20 and 21
F5/4 3
Control units UE IOS 21 and 22
Control unit CCM 10
F5/5 10 Radio
F5/6 5 Hand-held control
F5/7 – Unassigned
F5/8 – Unassigned
1)
Additional equipment
