Malfunctions during crane operation
14.8 Fuses in the crane cab
Operating manual 3 302 819 en 14 - 73
GMK3060
13.12.2018
s
Designation Amperage (A) Function
F2/1 3 Control unit UB IOS 20
F2/2 15 CCS display
F2/3 15 Control unit UB IOS 22
F2/4 15 Control unit UB IOS 22
F2/5 10 Control unit UB IOS 21
F2/6 10 Heater fan
F2/7 – Unassigned
F2/8 2 AGND SCM
Designation Amperage (A) Function
F3/1 3
Crane control power supply
CCS display
F3/2 5
Control lever supply
CAN bus system
F3/3 5
Instrument lighting
Control unit for auxiliary air heating system
F3/4 5
Control lever supply
RCL display (on the outside of the
crane cab)
F3/5 10
Central lubrication
Windscreen wiper/washing system
F3/6 20 Spotlight
F3/7 15 Heater fan
F3/8 – Unassigned
1)
Additional equipment
