13.4 Assigning a result automatically to a common variable
ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿
110
ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿
917 Coulometer
Document message
In the determination data it will be documented, that the time interval
has been expired.
Cancel determination
The determination is stopped.
13.4 Assigning a result automatically to a common varia-
ble
NOTICE
This instruction is based on the assumption that the method contains a
calculation command with a calculation.
Proceed as follows to assign a result to a common variable:
1
Opening the editing dialog of the result
ï¿ In the command list, select the command CALC.
ï¿ Tap on the [Edit command] button.
ï¿ Select the result whose value is to be assigned to a common vari-
able and tap on [Edit].
The editing dialog of the result is displayed.
2
Define result options
ï¿ Tap on the [Result options] button.
ï¿ Activate the parameter Save as common variable.
ï¿ Define Variable = CV01…CV25.
