14.4 Output lines
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
124
￭￭￭￭￭￭￭￭
917 Coulometer
14.4.1 Editing the output signal
List of input signals: Output signal ▶ New / Edit
Signal name
Designation of the template.
Entry 24 characters maximum
Output signal
Entering the desired bit pattern:
Entering the bit pattern:
￭ 0 = line inactive
￭ 1 = line active
￭ * = retain line status
￭ p = set pulse
The output lines are always numbered from right to left, i.e. with the sig-
nal *************1 line 0 is set.
NOTICE
We recommend masking lines that are of no interest or for which no
defined condition can be predicted with an asterisk (*).
Entry
Bit pattern of exactly 14 characters
Default value **************
Pulse length
Duration of the sent pulses.
Input range 100 - 1000 ms
Default value 200 ms
