28.3 Measurements (MEAS)
ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿
240
ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿
917 Coulometer
Temperature
This parameter is not available with the MEAS T command (temperature
measurement).
Temperature entered manually. The temperature is being continuously
measured when a temperature sensor is connected and when Temp.
measurement = automatic or continuous is defined (see sensor dialog
of the command).
Input range –20.0 - 150.0 °C
Default value 25.0 °C
Time interval MP
Time interval for entering a measuring point in the measuring point list.
The measuring point list is limited to 1000 measuring points.
Input range 0.1 - 999999.0 s
Default value 2.0 s
28.3.2 Sensor
The parameters for the sensor are edited under [Sensor].
The parameters are valid for all measuring modes except for Temp. mea-
surement. This parameter is not available with the MEAS T command
(temperature measurement).
Measuring input
Selection of the measuring input the sensor is connected to. The selection
is not dependent on whether the control device has one or two measur-
ing interfaces.
Selection 1 | 2
Default value 1
Sensor
Selection of the sensor from the sensor list. The selection depends on the
measuring mode. Sensors are defined under System â–¶ Sensors. You can
also enter a sensor name which is not contained in the sensor list. When a
determination is started there is a check whether the sensor is contained
in the sensor list.
Selection Selection of configured sensors
I(pol)
The polarization current is the current that is applied to a polarizable elec-
trode during voltametric measurement. This parameter is available only
with I(pol) determinations.
