27.2 Measuring
ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿
210
ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿
917 Coulometer
3
Enter a measuring temperature
ï¿ Enter the measuring temperature if no temperature sensor is con-
nected. If a temperature sensor is connected, then the tempera-
ture will be measured automatically.
4
Starting the measurement
ï¿ Tap on [Start].
The measured value display is opened:
The ongoing measurement is canceled with [Stop]. The label
switches once again to [Start].
27.2.1 Parameter description
"Manual control / Measure" dialog
Sensor
Selection of the sensor from the sensor list. Sensors are defined under
System â–¶ Sensors.
Selection Selection of configured sensors
Measuring input
Selection of the measuring input the sensor is connected to. The selection
depends on whether the control device has one or two measuring interfa-
ces.
Selection 1 | 2
Default value 1
Measuring mode
Selection of the measuring mode. Only those measuring modes are dis-
played which are advisable for the selected sensor.
Selection Ipol | Upol | T
Ipol
voltametric measurement with selectable polarization current
Upol
amperometric measurement with selectable polarization voltage
T
temperature measurement
Temperature
Temperature entered manually. If a temperature sensor is connected, then
the temperature will be measured continuously.
