28 Parameter
917 Coulometer
ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿
283
[Note]
Entering a note on the subsequence.
Dialog "Subsequence options / Note"
A short text can be entered in this dialog, e.g. for the description of the
subsequence commands or for the application purpose.
[Display options]
Definition when the note is being displayed.
Automatically after loading the subsequence
on | off (Default value: off)
If this parameter is activated, the note is displayed when loading the sub-
sequence. It can otherwise only be read in this dialog.
28.10 Miscellaneous commands
28.10.1 Controlling a stirrer (STIR)
A stirrer is controlled with the command STIR.
Control device
Selection Selection of configured control devices
Stirrer
Selection of the MSB connector the stirrer is connected to. The selection
does not depend on the number of MSB connectors of the control instru-
ment.
Selection 1 | 2 | 3 | 4
Default value 1
Status/Duration
Switching the stirrer on or off.
Input range 0 - 999 s (Increment: 1)
During this time the stirrer is running.
Selection on | off
Default value on
on
The stirrer is switched on. The stirrer runs until it is explicitly switched
off. If the determination is canceled with the key [ ], the stirrer is
also switched off.
off
The stirrer is switched off.
