4 Installation
917 Coulometer
ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿
15
4.3 Connecting the coulometer to the power supply
Connecting the power supply unit
The 917 Coulometer has an external power supply unit for a 24 V power
supply (DC). This is connected to the power socket of the coulometer.
WARNING
An incorrect supply voltage can damage the instrument.
Operate the instrument only with the supply voltage specified for it. Use
the supplied power supply unit exclusively, see Technical specifications
chapter.
Figure 7 Connecting the power supply unit
Proceed as follows:
1
Connect the plug of the external power supply unit with the power
socket of the coulometer.
