Metrohm 917 - Figure 12 Screwing the Electrode Cable to the Indicator Electrode; Figure 13 Connecting an Indicator Electrode

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
4 Installation
917 Coulometer
￭￭￭￭￭￭￭￭
19
2
6.2104.020
Figure 12 Screwing the electrode cable to the indicator electrode
Connecting the electrode cable to the coulometer
1
Plug the electrode plug into the Ind. socket of the coulometer.
Figure 13 Connecting an indicator electrode
