14 Templates
917 Coulometer
￭￭￭￭￭￭￭￭
123
Signal name Output signal Function
Meter Mode T *********0010* switches the 780/781 pH/Ion meter to tempera-
ture measurement and starts the measurement.
Meter Mode U *********0011* switches the 780/781 pH/Ion meter to voltage
measurement and starts the measurement.
Start device* ********p****p starts Devices 1 and 2 (e.g. Titrino, Titrando, etc.)
*)
.
The signal is transmitted as a short pulse of 200
ms.
Start device1 *************p starts Device 1 (e.g. Titrino, Titrando, etc.)
*)
.
The signal is transmitted as a short pulse of 200
ms.
Start device2 ********p***** starts Device 2 (e.g. Titrino, Titrando, etc.)
*)
.
The signal is transmitted as a short pulse of 200
ms.
Start Dos* *****p*p****** starts Dosimat at Devices 1 and 2 (Titrino via "acti-
vate").
The signal is transmitted as a short pulse of 200
ms.
Start Dos1 *******p****** starts Dosimat at Device 1 (Titrino via "activate").
The signal is transmitted as a short pulse of 200
ms.
Start Dos2 *****p******** starts Dosimat at Device 2 (Titrino via "activate").
The signal is transmitted as a short pulse of 200
ms.
*)
In the case of the 780/781 pH/Ion meter, a result report is triggered.
[New]
Add a new output signal to the list, see following chapter.
[Delete]
Delete the selected output signal from the list.
[Edit]
Edit the data of the selected output signal, see following chapter.
