28.8 Communication
ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿
278
ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿
917 Coulometer
Remote Box
Selection of the MSB connector the Remote Box is connected to. The
selection does not depend on the number of MSB connectors of the con-
trol instrument. The remote signal defined is sent via this Remote Box.
Selection 1 | 2 | 3 | 4
Default value 1
Output signal
Selection of the signal out of the templates or entering the required bit
pattern. Templates are defined under System â–¶ Templates â–¶ Output
lines.
NOTICE
A line set active is not being reset automatically, not even at the end of
the determination.
Entering a bit pattern:
ï¿ 0 = line inactive
ï¿ 1 = line active
ï¿ * = retain line status
ï¿ p = set pulse
The output lines are always numbered from right to left, i.e. with the sig-
nal *************1 line 0 is set. With a pulse, the length is set to 200 ms.
If it is required to set pulses with other lengths, you have to define a corre-
sponding template.
NOTICE
We recommend masking lines that are of no interest or for which no
defined condition can be predicted with an asterisk (*).
Entry
Bit patterns containing exactly 14 characters
or a max. of 24 characters for the name of
the template
Default value **************
Selection Selection of the templates defined
