6 Operation
917 Coulometer
ï¿ï¿ï¿ï¿ï¿ï¿ï¿ï¿
35
Number editor
Table 5 Editing functions
[OK] The modification is applied and the editing dialog
is exited.
[Cancel] The editing dialog is exited without applying the
modification.
[Delete entry] The content of the input field is deleted com-
pletely.
[off] If not only numbers but also special values (e.g.,
off) can be entered, then the corresponding but-
tons will be shown to the right of the numerical
keypad.
[R1] For many parameters, a result previously defined
in the method can also be entered in place of a
number (see chapter 31.6, page 300). You can
select the result variable by touching [R1].
NOTICE
A commercially available USB keyboard can be connected to make it
easier for text and numerical input. The key assignment is described in
chapter 10.8, page 82.
