Moog ACV with CANopen bus interface 6 Signal routing and scaling
Drive transducer interface
B99224-DV018-D-211, Rev. A, October 2018 75
6.3.9.1 Object 0x6200: Max interface number
This parameter indicates the number of available transducer interfaces in the servo valve.
6.3.9.2 Object 0x6201: Interface number
This parameter defines the actual referenced interface.
Value description
Drive_ActualValueConditioning
Index Sub-index Parameter name Data type Access
Per-
sistence
Value
range Default
0x6200 0 MaxInterfaceNumber UINT8 ro - UINT8 8
Drive_ActualValueConditioning
Index Sub-index Parameter name Data type Access
Per-
sistence
Value
range Default
0x6201 0 InterfaceNumber UINT8 rw N 1…48 None
<InterfaceNumber> Description
11
st
interface selected for configuration
22
nd
interface selected for configuration
33
rd
interface selected for configuration
44
th
interface selected for configuration
55
th
interface selected for configuration
66
th
interface selected for configuration
77
th
interface selected for configuration
88
th
interface selected for configuration
All other values Reserved
Table 40: Possible values of parameter <InterfaceNumber> (0x6201)
