Moog ACV with CANopen bus interface 7 Servo valve functions
Spool position setpoint conditioning / demand value generator
B99224-DV018-D-211, Rev. A, October 2018 139
7.2.4.1 Object 0x6322: Factor
This parameter is a slope factor by which the input is multiplied. It is defined by two signed integer values, the
numerator (upper 16 bits of the parameter) and the denominator (lower 16 bits of the parameter).
Value description
7.2.4.2 Object 0x6323: Offset
This parameter is the offset of the linear output function.
 Chapter "2.4.3 Units and prefix parameter", page 12
ValvePositionControl_DemandValueGenerator_Scaling
Index Sub-index Parameter name Data type Access
Per-
sistence Value range Default
0x6322 0 Factor UINT32 rw Y UINT32 0x00010001
<Factor>
Bit
31 16 15 0
Description #Numerator# #Denominator#
Table 71: Data structure of the slope factor
ValvePressureControl_DemandValueGenerator_Scaling
Index Sub-index Parameter name Data type Access
Per-
sistence Value range Default
0x6323 1 Offset INT16 rw Y INT16 0
0x6323 2 Unit UINT8 ro - UINT8 0
0x6323 3 Prefix INT8 ro - INT8 0
