Moog ACV with CANopen bus interface 8 Diagnostics
Troubleshooting
B99224-DV018-D-211, Rev. A, October 2018 281
8.4.1.6 0x06: Power supply voltage too high
8.4.1.7 0x07: Internal supply voltage too low
8.4.1.8 0x08: Internal supply voltage too high
8.4.1.9 0x0D: Electronics temperature too low (< –20 °C)
8.4.1.10 0x0E: Electronics temperature too high (> 85 °C)
Error Code: 0x06
Error Name: Power supply voltage too high
Description: Power supply voltage exceeds upper limit of 32 V
Severity of error: Minor
Action: Check power supply
Error Code: 0x07
Error Name: Internal supply voltage too low
Description: Internal power supply for the processor is too low
Severity of error: Major
Action: Send valve back to factory service
Error Code: 0x08
Error Name: Internal supply voltage too high
Description: Internal power supply for the processor is too high
Severity of error: Major
Action: Send valve back to factory service
Error Code: 0x0D
Error Name: Electronics temperature too low (< –20 °C)
Description: Temperature of the electronic is less than –20 °C
Severity of error: Minor
Action: • Check environmental temperature
• Consider additional protection cover or heating
Respect temperature limit (–20 °C to +80 °C).
Error Code: 0x0E
Error Name: Electronics temperature too high (> 85 °C)
Description: Temperature of the electronic is greater than 85° C
Severity of error: Minor
Action: • Check environmental temperature
• Consider additional protection cover or cooling
Respect temperature limit (–20 °C to +80 °C).
