Moog ACV with CANopen bus interface 7 Servo valve functions
Monitoring
B99224-DV018-D-211, Rev. A, October 2018 236
7.15.2.2 Object 0x63D2: Delay time
The delay time defines the minimal duration of a control deviation before a fault is active. The Time is set to
zero if the position is inside the window, if the fault is acknowledged or if one of the following parameters is
changed: <Type> (0x63D1), <UpperThreshold> (0x63D4), <LowerThreshold> (0x63D5) or
<DelayTime> (0x63D2).
 Chapter "2.4.3 Units and prefix parameter", page 12
7.15.2.3 Object 0x63D4: Upper threshold
This parameter defines the upper threshold of the control deviation's tolerance band.
 Chapter "2.4.3 Units and prefix parameter", page 12
7.15.2.4 Object 0x63D5: Lower threshold
This parameter defines the lower threshold of the control deviation's tolerance band.
 Chapter "2.4.3 Units and prefix parameter", page 12
ValvePressureControl_ControlMonitoring
Index Sub-index Parameter name Data type Access Persistence Value range Default
0x63D2 1 DelayTime UINT16 rw Y UINT16 30
0x63D2 2 Unit UINT8 ro - UINT8 3
0x63D2 3 Prefix INT8 ro - INT8 –3
ValvePressureControl_ControlMonitoring
Index Sub-index Parameter name Data type Access Persistence Value range Default
0x63D4 1 UpperThreshold INT16 rw Y INT16 512
0x63D4 2 Unit UINT8 ro - UINT8 0
0x63D4 3 Prefix INT8 ro - INT8 0
ValvePressureControl_ControlMonitoring
Index Sub-index Parameter name Data type Access Persistence Value range Default
0x63D5 1 LowerThreshold INT16 rw Y INT16 –512
0x63D5 2 Unit UINT8 ro - UINT8 0
0x63D5 3 Prefix INT8 ro - INT8 0
