Moog ACV Series - Object 0 X5 E44: Digital Output Value; Local CAN

Moog ACV with CANopen bus interface 6 Signal routing and scaling
Local CAN
B99224-DV018-D-211, Rev. A, October 2018 102
6.8.3 Object 0x5E44: Digital output value
The <DigitalOutputValue> (0x5E44) shows the state of the digital outputs.
6.9 Local CAN
The servo valve has a local CAN connector X2 or X10 which can be used to
• connect the Moog Valve and Pump Configuration Software to the servo valve.
• connect an external CAN device to the servo valve e.g. a position sensor or a pressure transducer.
The following CAN protocols are supported:
• Process data object (PDO) protocol
 Chapter "6.9.2 Local CAN process data object (PDO)", page 105
• Service data object (SDO) communication
The SDO communication will be handled by (vendor specific) parameters. With these parameters, a
gateway between the field bus and the local CANs SDO channel is realized.
 Chapter "6.9.6 Local CAN service data object (SDO) gateway", page 119
• Network management (NMT) protocol
The NMT protocol command "start remote node" is supported.
 Chapter "6.9.1.3 Object 0x5B02: Start remote node", page 104
• Synchronization (SYNC) producer protocol (implemented indirectly)
If a synchronous transition is needed, a SYNC-telegram can be emulated using one of the transmit PDO
channels.
 Chapter "6.9.7 Local CAN Synchronization (SYNC) producer protocol emulation", page 121
ValveDigitalOutputMonitor
Index Sub-index Parameter name Data type Access
Per-
sistence Value range Default
0x5E44 1 DigitalOutputValue_0 UINT8 ro - 0…1 None
0x5E44 2 DigitalOutputValue_1 UINT8 ro - 0…1 None
If one application parameter is written by the local CAN interface and the field bus by the same cy-
cle, the parameter last written will be processed.
