Moog ACV with CANopen bus interface 7 Servo valve functions
Pressure controller
B99224-DV018-D-211, Rev. A, October 2018 170
7.5.7 Object 0x2418: Controller output
This parameter holds the controller output of the pressure controller.
7.5.8 Active parameter set number
The pressure controller contains objects to influence the control behavior.
To adapt the control behavior to different control conditions within the machine cycle, 16 parameter sets are
provided. Within these sets most of the controller parameter can be configured.
Only one of the 16 parameter sets is used at the same time. The parameter set to be used is selected by
<ActiveParameterSetNumber> (0x2350). This parameter defines the parameter set number of the objects
which is used for the pressure controller. The following table shows all pressure controller objects that are part
of one parameter set.
ValvePressureControl
Index Sub-index Parameter name Data type Access
Per-
sistence Value range Default
0x2418 0 ControllerOutput INT16 ro - INT16 None
Index Object name
0x2303 Ramp slope
0x230D Active transducer interface
0x230F Transducer interface area B
0x2304 Proportional gain
0x230E Proportional gain time constant
0x2305 Integrator gain
0x2306 Integrator factor
0x2307 Integrator control range
0x231A Integrator upper output limit
0x231B Integrator lower output limit
0x5861 Integrator proportional part P gain
0x2308 Differentiator gain
0x2309 Differentiator T1
0x5863 Differentiator gain 2
0x5864 Differentiator T1 2
0x230A Upper output limit
0x230B Lower output limit
0x5867 Feed forward gain
0x5868 Feed forward parameter
0x5870 Feed forward offset
0x5865 Upper controller output limit
0x5866 Lower controller output limit
0x586C pQ switching mode
0x230C Hydraulic capacity
Table 81: Pressure controller objects contained in a parameter set
The objects which are part of the parameter set are signed with a sub-index N (1…16) in brackets
after the index number. E.g. (0x2304[N]).
