Moog ACV with CANopen bus interface 8 Diagnostics
Troubleshooting
B99224-DV018-D-211, Rev. A, October 2018 280
8.4 Troubleshooting
8.4.1 Fault code descriptions
8.4.1.1 Not implemented fault
8.4.1.2 0x02: Error during startup
8.4.1.3 0x03: Error DSP program download
8.4.1.4 0x04: Error DSP realtime data transmission
8.4.1.5 0x05: Power supply voltage too low
Error Code: Various
Error Name: Not implemented fault
Description: Fault is not implemented until now. This fault is a placeholder and the implementation
is planned for further version.
Severity of error: None
Action: None
A fault reaction may be configured, but won't have any impact on the valve. The fault never will be
thrown.
Error Code: 0x02
Error Name: Error during startup
Description: Internal error during startup
Severity of error: Major
Action: Send valve back to factory service
Error Code: 0x03
Error Name: Error DSP program download
Description: Internal error during startup
Severity of error: Major
Action: Send valve back to factory service
Error Code: 0x04
Error Name: Error DSP realtime data transmission
Description: Internal communication error during runtime
Severity of error: Major
Action: Send valve back to factory service
Error Code: 0x05
Error Name: Power supply voltage too low
Description: Power supply voltage exceeds lower limit of 18 V
Severity of error: Minor
Action: Check power supply
