Bit 10: Axis install mode negative direction

If the servo valve is in <DeviceMode> (0x6042) = 3 (Install mode) or <DeviceMode> (0x6042) = 4 (reference

mode), then the hydraulic axis can be moved with bit 10 of the <ControlWord> (0x6040) in negative direction.

The velocity of the movement is defined in the parameter <ManualMaxSpeed> (0x5614). If an incremental en-

coder is used to measure the axis position then <DeviceMode> (0x6042) = 4 (reference mode) is used to run

the homing position to calibrate the incremental encoder.

 Chapter "6.6.4 Incremental Encoder", page 96

 Chapter "7.7 Axis position setpoint conditioning / demand value generator", page 191

Bit 15: Ramp stop

If this bit is set, the spool position ramp and the pressure ramp output are frozen.

Spool position demand value generator:  Chapter "7.2.5 Ramp", page 140

Pressure demand value generator:  Chapter "7.4.5 Ramp", page 162

5.1.3 Object 0x4040: Local control word

Parameter description:  Chapter "5.1.2 Object 0x6040: Control word", page 44

Value description

Same values as <ControlWord> (0x6040)

 Table 30, page 44

5.1.4 Object 0x403F: Local control word default

The <LocalControlWordDefault> (0x403F) defines the control word after power up of the digital servo valve.

During startup of the servo valve, the parameter <LocalControlWordDefault> (0x403F) is copied to the param-

eter <LocalControlWord> (0x4040).

Device

Index Sub-index Parameter name Data type Access

Persis-

tence

Value

range Default

0x4040 0 LocalControlWord UINT16 rw N UINT16 <LocalControl-

WordDefault>

(0x403F)
