Moog ACV with CANopen bus interface 6 Signal routing and scaling
Analog inputs
B99224-DV018-D-211, Rev. A, October 2018 89
6.4.4 Analog input 3
6.4.4.1 Object 0x3218: Input type
This input type describes the supported electrical signal for the analog input 3.
Value description
 Table 45, page 88
6.4.4.2 Object 0x321C: Actual value
Actual value of the analog input 3.
6.4.5 Analog input 4
6.4.5.1 Object 0x3220: Input type
This input type describes the supported electrical signal for the analog input 4.
Value description
 Table 45, page 88
6.4.5.2 Object 0x3224: Actual value
Actual value of the analog input 4.
6.4.6 Internal pressure transducer input
The internal pressure transducer input is located in the servo valve port A. This transducer can also be used
as input for the controller.
 Chapter "6.3.9 Transducer interface definition", page 74
AnalogInput3
Index Sub-index Parameter name Data type Access
Persis-
tence Value range Default
0x3218 0 AnaInpType3 INT8 rw Y INT8 2
AnalogInput3
Index Sub-index Parameter name Data type Access
Persis-
tence Value range Default
0x321C 0 AnaInpActualValue3 INT16 ro - INT16 None
AnalogInput4
Index Sub-index Parameter name Data type Access
Persis-
tence Value range Default
0x3220 0 AnaInpType4 INT8 rw Y INT8 2
AnalogInput4
Index Sub-index Parameter name Data type Access
Persis-
tence Value range Default
0x3224 0 AnaInpActualValue4 INT16 ro - INT16 None
