Moog ACV with CANopen bus interface 7 Servo valve functions
Flow control
B99224-DV018-D-211, Rev. A, October 2018 220
7.12.5.1 Object 0x5205: Flow control mode
The flow control mode selects the pressure sensor configuration.
Value description
ValveFlowControl
Index Sub-index Parameter name Data type Access
Per-
sis-
tence Value range Default
0x5205 0 FlwControlMode UINT8 rw Y 0…1 0
<FlwControlMode> Description
0 P-A, P-B edge
1 P-A, A-T edge
Table 87: Possible values of parameter <FlwControlMode> (0x5205)
