Moog ACV with CANopen bus interface 7 Servo valve functions
Data logger
B99224-DV018-D-211, Rev. A, October 2018 257
7.17.4.2 Object 0x3188: Trigger type
This parameter contains the trigger type of the data logger.
Value description
7.17.4.3 Object 0x318C: Trigger level or bitmask
This parameter contains the trigger level if the <TriggerCoupling> (0x318A) is set to 0 or 1.
This parameter contains the BITMASK if the <TriggerCoupling> (0x318A) is set to 2. The BITMASK selects
the bits to be compared with the trigger signal.
7.17.4.4 Object 0x318A: Trigger coupling
This parameter contains the trigger coupling type of the data logger.
Value description
DataLogger
Index Sub-index Parameter name Data type Access Persistence Value range Default
0x3188 0 TriggerType UINT8 rw Y 0…2 1
<TriggerType> Description
0 FREE (the trigger condition is always true).
1 NORMAL (if the trigger condition matches, the data logger returns to wait state completed).
2 SINGLE (if the trigger condition matches, the data logger enters the ready state).
Table 106: Possible values of parameter <TriggerType> (0x3188)
DataLogger
Index Sub-index Parameter name Data type Access Persistence Value range Default
0x318C 0 TriggerLevelOrBitmask INT32 rw Y INT32 0
DataLogger
Index Sub-index Parameter name Data type Access Persistence Value range Default
0x318A 0 TriggerCoupling UINT8 rw Y 0…2 1
<TriggerCoupling> Description
0 AC (AC part of the trigger signal is passed and is compared with the trigger level).
1 DC (the trigger signal is passed directly and is compared with the trigger level).
2 BITMASK (the trigger signal is passed directly and is compared bit-wise with the trigger bitmask).
Table 107: Possible values of parameter <TriggerCoupling> (0x318A)
